ASME B16.5 / ANSI B16.47 150# & 300#
Table of Content:
Taurus Piping Solutions (TPS) is an industry-leading manufacturer and exporter of the Monel 400 Backing Ring Flanges. The Monel 400 Backing Ring Flanges that we produce are widely popular in the industry because of the superlative quality and dimensional accuracy that they offer. We produce and supply these Monel 400 Backing Ring Flanges in different sizes, specifications, pressure classes and dimensions according to the requirements of our customers at the most reasonable prices. We believe in providing complete customer satisfaction and hence we produce the Monel 400 Backing Ring Flanges that offer in excellent toughness, even down to cryogenic temperatures. We use some of the superior quality raw materials and latest technology for manufacturing Monel 400 SOFF Backing Ring Flanges which results in the manufacturing of the superlative product.
Monel 400 Backing Ring Flanges have high strength and excellent resistance to corrosion in a range of media especially sea water, hydrofluoric acid, sulphuric acid and alkalis. Monel 400 Backing Ring Flanges works in a wide range of temperatures and has exceptionally good dimensional stability. Monel 400 Backing Ring Flanges offers superior resistance to many corrosive environments.
Applications of the Monel 400 Backing Ring Flanges are found in areas where better formability is required. These Monel 400 Backing Ring Flanges are used in Off-Shore Oil Drilling Companies and Sea Water Equipment manufacturing. Pulp and Paper Industry, Condensers and Petrochemical Industries etc.
As a customer-centric company, these Monel 400 SOFF Backing Ring Flanges are thoroughly checked for different quality measures to ensure that our customers receive flawless products. We also provide various test certificate and documents along with our Monel 400 Backing Ring Flanges. We at Taurus Piping Solutions are the leading Monel 400 Backing Ring Flanges Exporter in various regions like Australia, New Zealand, Dubai, Abu Dhabi, Oman, Saudi Arabia, South Africa, Canada, Qatar, Bahrain, USA, etc.
| Standard | W.N. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
| Grade | C | Mn | Cu | S | Si | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Monel 400 | 0.3 max | 2.0 max | 28.0 – 34.0 | 0.02 max | 0.5 max | 1.0 – 2.5 | 63.0 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Commercial Invoice including HS Code
Packing List including Complete Details
Certificate of Origin legalized
Material Traceability Records
Quality Assurance Plan (QAP)
Heat Treatment Charts
Material Test Certificates (MTC)
NABL approved Laboratory Test Reports
