ASME B16.5 / ANSI B16.47 150# & 300#
Table of Content:
Taurus Piping Solutions (TPS) is a prominent manufacturer and exporter of Nickel 201 Backing Ring Flanges. We fabricate these Nickel 201 Backing Ring Flanges using high quality raw material and latest technology in accordance with national and international quality standards. We supply these Nickel 201 Flange Backing Ring in various specifications, sizes, dimensions, pressure classes and also in customized specifications as per the requirement of our clients at the most affordable prices.
Nickel 201 Backing Ring Flanges are resistant to acids and alkalis, and dry gases at room temperature, and also resistant to mineral acids depending on the temperature and concentration of the solution. Nickel 201 SOFF Backing Ring Flanges have outstanding resistance to corrosion in acids and alkalis and is most useful under reducing conditions, and outstanding resistance to caustic alkalis up to and including the molten state.
Nickel Alloy UNS N02201 Backing Ring Flanges exhibit resistance to all dry gases at room temperature and in dry chlorine and hydrogen chloride may be used in temperatures up to 550 degrees C and are resistant to mineral acids varies according to temperature and concentration and whether the solution is aerated or not. Nickel 201 Backing Ring Flanges are resistant to intergranular attack above 315 degrees C.
Nickel Alloy 201 Slip on Flat Face Backing Ring Flanges are used in manufacturing and handling of sodium hydroxide, particularly at temperature above 300 degrees C, analine hydrochloride production, manufacture of vinyl chloride monomer, reactors and vessels in which fluorine is generated and reacted with hydrocarbons, etc.
We conduct various tests on our flanges to ensure only superior quality flanges are delivered to our clients. We at Taurus Piping Solutions are the leading Nickel Alloy 201 Backing Ring Flanges Exporter in various regions like Australia, New Zealand, Dubai, Abu Dhabi, Oman, Saudi Arabia, South Africa, Canada, Qatar, Bahrain, USA, etc.
| Standard | W.N. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | - | LC-Ni 99 |
| Grade | C | Mn | Cu | S | Si | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Nickel 201 | 0.02 max | 0.35 max | 0.25 max | 0.01 max | 0.35 max | 0.40 max | 99.0 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
Commercial Invoice including HS Code
Packing List including Complete Details
Certificate of Origin legalized
Material Traceability Records
Quality Assurance Plan (QAP)
Heat Treatment Charts
Material Test Certificates (MTC)
NABL approved Laboratory Test Reports
